• SND

    SND

    FEATURE
      ˙ SMD Type
      ˙ Low DC resistance.
      ˙ Suitable for large currents.
      ˙ Ideal for a variety of DC-DC converter inductor applications.
      ˙ Available on tape and reel for auto surface mounting.

    APPLICATION
      ˙ DC/DC converter   ˙ Digital Camera
      ˙ Camcorder   ˙ G.P.S.
      ˙ LCD TV   ˙ Portable CDR-W
      ˙ MP3-player   ˙ PDA (desktop)

    Specification

Please Click products below, and click Add to Inquiry List for inquiry.
Photo Series Product Name Download A B C D TYP. Select

SND 03011

3.3±0.3
3.0±0.3
1.1±0.3
1

SND 03015(1μH~ 2700μH)

3.3±0.3
3.0±0.3
1.5±0.3
1

SND 03021(1μH~ 2700μH)

3.3±0.3
3.0±0.3
2.1±0.3
1

SND 0302(1μH~ 820μH)

3.0±0.3
2.8±0.3
2.5±0.3
0.8

SND 0403(1μH~ 2200μH)

4.5±0.3
4.0±0.3
3.2±0.3
1.3

SND 0502(1μH~ 1500μH)

5.8±0.3
5.2±0.3
2.5±0.3
1.3

SND 0503(1μH~ 470μH)

5.8±0.3
5.2±0.3
3.0±0.3
1.3

SND 0504(1μH~ 1000μH)

5.8±0.3
5.2±0.3
4.5±0.3
1.3

SND 0703(1μH~ 470μH)

7.8±0.3
7.0±0.3
3.5±0.3
2.1

SND 0705(1μH~ 1800μH)

7.8±0.3
7.0±0.3
5.0±0.3
2.1

SND 1004(1μH~ 1000μH)

10.0±0.3
9.0±0.3
4.0±0.3
2.1

SND 1005(1μH~ 1000μH)

10.0±0.4
9.0±0.4
5.4±0.3
2.1

SND 1006(1μH~ 1200μH)

11.0Max.
10.0Max.
7.5Max.
2.1

SND 1008(1μH~ 1200μH)

11.0Max.
10.0Max.
8.5Max.
2.1
