    AWI

    FEATURE
      ˙ Lead-free electrodes.
      ˙ Very strong solderability by reflow soldering and soldering iron or wave soldering.
      ˙ Highly accurate dimensions can be mounted automaticlly.
      ˙ Terminals are highly resistant to pull forces.
      ˙ High reliable in environments of sudden temperature change and humidity.
      ˙ Highly resistant to mechanical shocks and presure.
      ˙  Superior Q characteristics and broadest selections amount peers.

    APPLICATION
      ˙ Micro TVs, liquid crystal TVs, video cameras, protable VCRs, car radios, car stereos,
    thin radios, television tuners, mobile phones, radio and other electronic devices.


    Specification

Please Click products below, and click Add to Inquiry List for inquiry.
Photo Series Product Name Download Inductance
(μH ) 		Q Min. LQ Test
Frequency
(MHz) 		Self Resonant
Frequency
(MHz) Min. 		DC Resistance Rdc
(Ω)Max. 		Rated Current Idc
(mA) Max. 		Select

AWI-252018-R22

0.22
25
25.2
230
0.5
430

AWI-252018-R27

0.27
25
25.2
210
0.55
420

AWI-252018-R33

0.33
25
25.2
190
0.6
400

AWI-252018-R39

0.39
25
25.2
175
0.65
375

AWI-252018-R47

0.47
25
25.2
160
0.68
350

AWI-252018-R56

0.56
25
25.2
150
0.75
325

AWI-252018-R68

0.68
25
25.2
135
0.85
300

AWI-252018-R82

0.82
25
25.2
125
1
260

AWI-252018-1R0

1
25
7.96
115
1.11
245

AWI-252018-1R2

1.2
25
7.96
100
1.2
230

AWI-252018-1R5

1.5
25
7.96
90
1.3
220

AWI-252018-1R8

1.8
25
7.96
85
1.45
210

AWI-252018-2R2

2.2
25
7.96
80
1.55
200

AWI-252018-2R7

2.7
25
7.96
75
1.7
195

AWI-252018-3R3

3.3
25
7.96
65
1.9
185

AWI-252018-3R9

3.9
25
7.96
60
2.1
180

AWI-252018-4R7

4.7
25
7.96
55
2.3
175

AWI-252018-5R6

5.6
25
7.96
50
2.5
170

AWI-252018-6R8

6.8
25
7.96
45
2.7
165

AWI-252018-8R2

8.2
25
7.96
40
3.05
160

AWI-252018-100

10
25
2.52
32
3.5
155

AWI-252018-120

12
25
2.52
30
3.8
150

AWI-252018-150

15
25
2.52
28
4.4
140

AWI-252018-180

18
25
2.52
25
5
130

AWI-252018-220

22
25
2.52
22
5.8
125

AWI-252018-270

27
20
2.52
21
6.3
115

AWI-252018-330

33
20
2.52
20
7.1
110

AWI-252018-390

39
20
2.52
18
9.5
90

AWI-252018-470

47
20
2.52
17
11
80

AWI-252018-560

56
20
2.52
16
12.1
75

AWI-252018-680

68
20
2.52
15
16.6
70

AWI-252018-820

82
20
2.52
13
19
65

AWI-252018-101

100
15
0.796
12
21
60

AWI-322522-R12

0.12
30
25.2
500
0.22
450

AWI-322522-R15

0.15
30
25.2
450
0.25
450

AWI-322522-R18

0.18
30
25.2
400
0.28
450

AWI-322522-R22

0.22
30
25.2
350
0.32
450

AWI-322522-R27

0.27
30
25.2
320
0.36
450

AWI-322522-R33

0.33
30
25.2
300
0.4
450

AWI-322522-R39

0.39
30
25.2
250
0.45
450

AWI-322522-R47

0.47
30
25.2
220
0.5
450

AWI-322522-R56

0.56
30
25.2
180
0.55
450

AWI-322522-R68

0.68
30
25.2
160
0.6
450

AWI-322522-R82

0.82
30
25.2
140
0.65
450

AWI-322522-1R0

1
30
7.96
120
0.7
400

AWI-322522-1R2

1.2
30
7.96
100
0.75
390

AWI-322522-1R5

1.5
30
7.96
85
0.85
370

AWI-322522-1R8

1.8
30
7.96
80
0.9
350

AWI-322522-2R2

2.2
30
7.96
75
1
320

AWI-322522-2R7

2.7
30
7.96
70
1.1
290

AWI-322522-3R3

3.3
30
7.96
60
1.2
260

AWI-322522-3R9

3.9
30
7.96
55
1.3
250

AWI-322522-4R7

4.7
30
7.96
50
1.5
220

AWI-322522-5R6

5.6
30
7.96
47
1.6
200

AWI-322522-6R8

6.8
30
7.96
43
1.8
180

AWI-322522-8R2

8.2
30
7.96
40
2
170

AWI-322522-100

10
30
2.52
36
2.1
150

AWI-322522-120

12
30
2.52
33
2.5
140

AWI-322522-150

15
30
2.52
28
2.8
130

AWI-322522-180

18
30
2.52
25
3.3
120

AWI-322522-220

22
30
2.52
23
3.7
110

AWI-322522-270

27
30
2.52
18
5
80

AWI-322522-330

33
30
2.52
17
5.6
70

AWI-322522-390

39
30
2.52
16
6.4
65

AWI-322522-470

47
30
2.52
15
7
60

AWI-322522-560

56
30
2.52
13
8
55

AWI-322522-680

68
30
2.52
12
9
50

AWI-322522-820

82
30
2.52
11
10
45

AWI-322522-101

100
20
0.796
10
11
40

AWI-322522-121

120
20
0.796
10
12
70

AWI-322522-151

150
20
0.796
8
15
65

AWI-322522-181

180
20
0.796
7
17
60

AWI-322522-221

220
20
0.796
7
21
50

AWI-453232-R10

0.1
35
25.2
300
0.18
800

AWI-453232-R12

0.12
35
25.2
280
0.2
770

AWI-453232-R15

0.15
35
25.2
250
0.22
730

AWI-453232-R18

0.18
35
25.2
220
0.24
700

AWI-453232-R22

0.22
40
25.2
200
0.25
665

AWI-453232-R27

0.27
40
25.2
180
0.26
635

AWI-453232-R33

0.33
40
25.2
165
0.28
605

AWI-453232-R39

0.39
40
25.2
150
0.3
575

AWI-453232-R47

0.47
40
25.2
145
0.32
545

AWI-453232-R56

0.56
40
25.2
140
0.36
520

AWI-453232-R68

0.68
40
25.2
135
0.4
500

AWI-453232-R82

0.82
40
25.2
130
0.45
475

AWI-453232-1R0

1
50
7.96
100
0.5
450

AWI-453232-1R2

1.2
50
7.96
80
0.55
430

AWI-453232-1R5

1.5
50
7.96
70
0.6
410

AWI-453232-1R8

1.8
50
7.96
60
0.65
390

AWI-453232-2R2

2.2
50
7.96
55
0.7
380

AWI-453232-2R7

2.7
50
7.96
50
0.75
370

AWI-453232-3R3

3.3
50
7.96
45
0.8
355

AWI-453232-3R9

3.9
50
7.96
40
0.9
330

AWI-453232-4R7

4.7
50
7.96
35
1
315

AWI-453232-5R6

5.6
50
7.96
33
1.1
300

AWI-453232-6R8

6.8
50
7.96
27
1.2
285

AWI-453232-8R2

8.2
50
7.96
25
1.4
270

AWI-453232-100

10
50
2.52
20
1.6
250

AWI-453232-120

12
50
2.52
18
2
225

AWI-453232-150

15
50
2.52
17
2.5
200

AWI-453232-180

18
50
2.52
15
2.8
190

AWI-453232-220

22
50
2.52
13
3.2
180

AWI-453232-270

27
50
2.52
12
3.6
170

AWI-453232-330

33
50
2.52
11
4
160

AWI-453232-390

39
50
2.52
10
4.5
150

AWI-453232-470

47
50
2.52
10
5
140

AWI-453232-560

56
50
2.52
9
5.5
135

AWI-453232-680

68
50
2.52
9
6
130

AWI-453232-820

82
50
2.52
8
7
120

AWI-453232-101

100
40
0.796
8
8
110

AWI-453232-121

120
40
0.796
6
8
110

AWI-453232-151

150
40
0.796
5
9
105

AWI-453232-181

180
40
0.796
5
9.5
102

AWI-453232-221

220
40
0.796
4
10
100

AWI-453232-271

270
40
0.796
4
12
92

AWI-453232-331

330
40
0.796
3.5
14
85

AWI-453232-391

390
40
0.796
3
18
80

AWI-453232-471

470
40
0.796
3
26
62

AWI-453232-561

560
30
0.796
3
30
50

AWI-453232-681

680
30
0.796
3
30
50

AWI-453232-821

820
30
0.796
2.5
35
30

AWI-453232-102

1.00mH
30
0.252
2.5
40
30
